Oscar-II Series LED Street Light Best Seller with Tempered Glass Reasonable Price

Economic high efficiecny street lighting solution. This series has a cost advantage and elegant appearance.
  • Wattage25W~240W
  • Input Voltage100V-240V
  • Lumen Efficacy140-170lm/W
  • MaterialADC12 die-casting aluminum
  • Protection RatingIP66 / IK08
  • Independent Driver CompartmentYes
  • Tool-free Maintenanceno
  • InstallationCompatible to Post-top mounting and Side-entry mounting
  • Color Temperature2700K~6000K
  • C.R.I70
  • Driver BrandMeanwell/Moso/Sosen/Inventronics
  • Total Homonic Distortion<15%
  • Dimming1-10V; light sensor
  • Power Factor0.95
  • SocketNEMA; Zhaga
  • Light Distribution60°/90°/120°/T2M/T3M/T4M
  • Ambient Temperature-40℃-50℃
  • Warranty5 years
  • More Less
    • Model:
      25W
      50W
      60W
      75W
      80W
      100W
      120W
      150W
      180W
      200W
      240W
    Description Specifications
    Description

    Product Summary:
    The Oscar-II Series LED Street Light adopts
    die-casting aluminum plus tempered glass cover, flat honeycomb design for better heat dissipation. Compared with Oscar series, this series street light has cost advantage. This LED street lamp's adjustable arm supports both horizontal and vertical installation.



    Features and Benefits:

    • Flat honeycomb design,  integrated die-casting AL, good heat dissipation.
    • High luminous efficacy, 140-170lm/W.
    • Professional glare-free lens, 60°/90°/120°/T2M/T3M/T4M.
    • 0-10V dimming / time control / light sensor / lOT control available.
    • Angle of mounting shaft can be installed and adjusted 90°/180°(±15°).
    • Gradienter design, easy for horizontal adjustment.
    • 5 years warranty.


    Light Distribution Curve:
    light distribution curve of Oscar-II series light
    Dimension Drawig:
    dimension drawing of Oscar-II series light

    Shaft Drawing:
    Shaft Drawing of Oscar-II series light

    Installation angle can be adjusted:
    Oscar-II Series LED Street Light adjustable installation angle
    Application senarios:
    This series light is suitable for main road, high way, flyover, city street, overpass, sidewalk, square, school, residential district, industrial area, park etc.

    application senario of Oscar-II series light

    Specifications
    Model All Series (25W~240W)
    Input Voltage 100-240VAC, 50-60Hz
    PF 0.95
    Luminous Efficacy 140-170lm/W
    CCT 2700K~6000K
    THD 15%
    CRI Ra>70
    Beam Angle  60°/90°/120°/T2M/T3M/T4M
    LED Driver Meanwell/Moso/Sosen/Inventronics
    LED Chips Brand Lumileds
    Bracket  Diameter 42mm/50mm/60mm
    Housing  Die-casting ADC12
    Operating Temp. -40~50
    IP/IK Rating IP66 / IK08
    Warranty 5  years

    Model Oscar-II-25/50 Oscar-II-60/75 Oscar-II-80/100/120 Oscar-II-150/180 Oscar-II-200/240
    Power 25W/50W 60W/75W 80W/100W/120W 150W/180W 200W/240W
    Dimension (mm) 463*173*87  570*200*88 611*240*89 680*260*89 693*300*90
    Weight (kg) 2.54 3.3 4.2 5.0 5.9
